WayinTop 5pcs 360 Degree Rotary Encoder Module KY-040 Brick Sensor Development Board with Push Button for Arduino

WayinTop: We aim to make your work Easier & Funnier! Specification of Rotary Encoder Module: Model: KY-040 Working Voltage: 5V Material: PCB + Brass Weight: 10g Size: 32 x 19 x 30mm The pin outs for this rotary encoder are identified in the below. CLK: Encoder Pin A DT: Encoder Pin B SW: No Pushbutton Switch +: 5V Supply GND: Encoder Pin C Pin connected to for Arduino: CLK = [pin 3] DT = [pin 4] Button = [pin 5] + = [Pin 5V] GND = [pin GND] Pin connected to Raspberry Pi: CLK = GPIO16 [pin 36] DT = GPIO15 [pin 10] SW = GPIO14 [pin 8] + = 3.3V [pin 1] GND = ground [pin 6] Package Include: 5 x KY-040 360 Degree Rotary Encoder Module 5 x Encoder Push Button Black

Features

• [(General Parameters)] Model: KY-040, Working Voltage: 5V, One round number of pulse: 20.
• [(No Limited Rotation Counts)] The rotary encoder can count the number of pulse output during rotation in the positive direction and reverse direction through the rotation and this rotation counts are not limited.
• [(Encoder Key)] With the key on the rotary encoder, you can reset to the initial state, that is, counting from 0.
• [(Application)] Best choice for stepper and servo motor control. You could also use it to control devices like digital potentiometer.
• [(Package Included)] 5 x KY-040 360 Degree Rotary Encoder Module + 5 x Encoder Push Button
